ev.nz summary
The short version
The IONIQ 5 Series II is Hyundai New Zealand's current dedicated electric SUV on the 800V E-GMP platform. Four configurations are listed from $79,990 to $124,990 RRP (excluding on-road costs), with rear- or all-wheel drive, up to 570km of WLTP range and DC charging at up to 350kW.
Highlights
- Up to 570km WLTP range (84 kWh RWD)
- 10–80% in about 18 minutes at up to 350kW
- 5-star ANCAP rating (2021)
- Up to 1,600kg braked towing on long-range models
- 527L boot plus a frunk on RWD models
- V2L standard
Worth knowing
- Mechanical warranty is 3 years / 100,000km on the Series II page
- Roadside assist is also 3 years / 100,000km
- N Line Limited drops WLTP range to 495km
- AWD frunk shrinks to 24L
- IONIQ 5 N is outside the ANCAP rating used here
This summary is based on Hyundai New Zealand's IONIQ 5 Series II specification table and ANCAP data, checked on 24 October 2026. It is not a road test: ev.nz has not driven this car and does not give it a score.
NZ line-up and pricing
| Trim | Price (RRP) | Battery / drive | Range (WLTP) | Power |
|---|---|---|---|---|
| 63 kWh | $79,990 | 63 kWh, RWD | 440km | 125kW |
| 84 kWh | $89,990 | 84.8 kWh, RWD | 570km | 168kW |
| 84 kWh AWD | $97,990 | 84.8 kWh, AWD | 546km | 239kW |
| N Line Limited AWD | $124,990 | 84.8 kWh, AWD | 495km | 239kW |
Overview
The Hyundai IONIQ 5 Series II is Hyundai New Zealand's current medium electric SUV, built on the 800V Electric-Global Modular Platform. Four configurations are listed on the official page: 63 kWh rear-wheel drive ($79,990 RRP), 84 kWh rear-wheel drive ($89,990), 84 kWh all-wheel drive ($97,990) and N Line Limited AWD ($124,990). Prices exclude on-road costs.
The Standard Range model uses a 63 kWh battery and a 125kW / 350Nm rear motor for 440km of WLTP range. The Extended Range rear-drive model raises the battery to 84.8 kWh and power to 168kW for 570km. Dual-motor HTRAC AWD versions combine 239kW and 605Nm, with 546km of range on the standard AWD and 495km on the N Line Limited.
Charging is a strong point. Hyundai quotes 10–80% in about 18 minutes on a 350kW ultra-fast charger for every listed trim, and about 58 to 76 minutes on a 50kW charger. The on-board AC charger is 10.5kW; published 10–100% AC times are about 8 hr 10 min (63 kWh) to 10 hr 50 min (84.8 kWh) at 7kW. An external V2L adaptor can supply up to 3.6kW (230V / 15A).
Boot space is 527L with the seats up and 1,587L folded (520L / 1,580L on N Line Limited), plus a front boot of 57L on rear-drive models or 24L on AWD. Braked towing is 750kg on the 63 kWh model and 1,600kg on the long-range models.
ANCAP awarded the IONIQ 5 five stars in 2021 (all variants except the IONIQ 5 N; rating expires December 2027). Hyundai New Zealand lists a 3-year / 100,000km mechanical warranty, an 8-year / 160,000km high-voltage battery warranty, three years of roadside assistance and a 10-year / 200,000km anti-perforation body warranty.
Range and charging
Charging times are Hyundai New Zealand figures. The on-board AC charger is rated at 10.5kW; the published AC times are quoted at 7kW. Hyundai states the 800V architecture also supports 400V DC chargers without an adapter.
Gallery
Specifications
| Specification | 63 kWh | 84 kWh | 84 kWh AWD | N Line Limited AWD |
|---|---|---|---|---|
| Driven wheels | Rear-wheel drive | Rear-wheel drive | HTRAC all-wheel drive | HTRAC all-wheel drive |
| Combined power | 125kW | 168kW | 239kW | 239kW |
| Combined torque | 350Nm | 350Nm | 605Nm | 605Nm |
| Rear motor | 125kW / 350Nm | 168kW / 350Nm | 165kW / 350Nm | 165kW / 350Nm |
| Front motor | — | — | 74kW / 255Nm | 74kW / 255Nm |
| Specification | 63 kWh | 84 kWh | 84 kWh AWD | N Line Limited AWD |
|---|---|---|---|---|
| Battery capacity | 63 kWh | 84.8 kWh | 84.8 kWh | 84.8 kWh |
| Battery type | Lithium-ion polymer with water cooling | |||
| Range (WLTP) | 440km | 570km | 546km | 495km |
| Energy consumption (combined) | 15.6 kWh/100km | 16.0 kWh/100km | 16.8 kWh/100km | 18.1 kWh/100km |
| Drag coefficient | 0.291 | |||
| Specification | 63 kWh | 84 kWh | 84 kWh AWD | N Line Limited AWD |
|---|---|---|---|---|
| On-board AC charger | 10.5kW | |||
| Maximum DC charging speed | Up to 350kW | |||
| 350kW DC, 10–80% | Approx. 18 min | |||
| 50kW DC, 10–80% | Approx. 58 min | Approx. 76 min | Approx. 76 min | Approx. 76 min |
| 7kW AC, 10–100% | Approx. 8 hr 10 min | Approx. 10 hr 50 min | Approx. 10 hr 50 min | Approx. 10 hr 50 min |
| Vehicle-to-load (V2L) | Internal plug; external adaptor up to 3.6kW | |||
| Specification | 63 kWh | 84 kWh | 84 kWh AWD | N Line Limited AWD |
|---|---|---|---|---|
| Length / width / height | 4,635 / 1,890 / 1,600mm | 4,635 / 1,890 / 1,600mm | 4,635 / 1,890 / 1,600mm | 4,655 / 1,890 / 1,605mm |
| Wheelbase | 3,000mm | |||
| Ground clearance | 160mm | |||
| Kerb weight (lightest / heaviest) | 1,830–1,910kg | 1,910–1,990kg | 2,020–2,100kg | 2,045–2,125kg |
| Boot (seats up / folded, VDA) | 527L / 1,587L | 527L / 1,587L | 527L / 1,587L | 520L / 1,580L |
| Front boot (frunk) | 57L | 57L | 24L | 24L |
| Towing (braked / unbraked) | 750kg / 750kg | 1,600kg / 750kg | 1,600kg / 750kg | 1,600kg / 750kg |
| Turning radius | 5.99m | |||
| Wheels | 19" alloy | 19" alloy | 19" alloy | 20" alloy |
| Specification | 63 kWh | 84 kWh | 84 kWh AWD | N Line Limited AWD |
|---|---|---|---|---|
| Mechanical warranty | 3 years / 100,000km | |||
| High-voltage battery | 8 years / 160,000km | |||
| Roadside assistance | 3 years / 100,000km | |||
| Anti-perforation body | 10 years / 200,000km | |||
Specifications from Hyundai New Zealand's IONIQ 5 Series II page, checked 24 October 2026. Prices are recommended retail prices and exclude on-road costs. Battery capacities and WLTP ranges are as published by Hyundai New Zealand. The IONIQ 5 N is listed separately and is outside ANCAP's 2021 rating for the standard model.
Equipment
Highlighted by Hyundai NZ
- 800V E-GMP platform with up to 350kW DC charging
- 10.5kW on-board AC charger
- Wireless Apple CarPlay and Android Auto
- Twin 12.3-inch digital displays with satellite navigation
- Vehicle-to-load (V2L) up to 3.6kW
- Paddle-adjustable regenerative braking
- Seven airbags including a front centre airbag
- Smart Cruise Control with Stop & Go
- Dual-zone automatic climate control
- Heat pump (listed on Series II table)
Available on higher grades (per Hyundai NZ table)
- Wireless Apple CarPlay and Android Auto
- 12.3-inch touchscreen with satellite navigation and 12.3-inch driver display
- BOSE premium audio (8 speakers including subwoofer)
- Full relaxation front seats and sliding centre console
- Heat pump air-conditioning
- Remote Smart Park Assist and Surround View Monitor
- Heads-up display (augmented reality type on N Line Limited)
- N Line exterior styling and 20-inch alloys (N Line Limited)
Safety
Hyundai New Zealand lists seven airbags (dual front, side, curtain and a front-seat centre airbag) and SmartSense features including Forward Collision-Avoidance Assist with Junction Assist, Blind-Spot Collision-Avoidance Assist, Lane Keeping and Lane Following Assist, Smart Cruise Control with Stop & Go, Rear Cross-Traffic Collision-Avoidance Assist and a Surround View Monitor on higher grades. ANCAP's 5-star (2021) rating applies to all variants except the IONIQ 5 N.
Sources and verification
Every figure on this page was checked against these sources on 24 October 2026. Specs that could not be confirmed have been left out.
- Hyundai New Zealand: IONIQ 5 Series II Prices, performance, battery, charging, dimensions, equipment, warranty
- ANCAP: Hyundai Ioniq 5 safety rating 5 stars, 2021
Note: prices exclude on-road costs and can change; confirm with Hyundai New Zealand before buying. Mechanical warranty on this model is listed as 3 years / 100,000km on the Series II page (shorter than some other brands' vehicle warranties). Commercial/taxi use shortens the battery warranty to 3 years / 100,000km per Hyundai NZ footnote.
